Oxford researchers film the fleeting steps an enzyme takes to build penicillin's ring
Oxford researchers used X-ray lasers to film the enzyme IPNS building penicillin's beta-lactam ring, catching steps that last fractions of a second. Enzyme engineers now have a detailed starting point, but any benefit against resistant bacteria is further off.
The Scientist · Science desk

What happened
- The team caught a thioaldehyde that forms just before the ring closes and a monocyclic beta-lactam, the first ring-shaped structure on the way to the full penicillin scaffold.
- According to the release, IPNS performs the whole complex transformation in a single step, answering a mechanistic question left open for more than four decades.
- The researchers report that water molecules inside the enzyme, along with small movements across the protein, help guide the chemical steps.
- Oxford ran the work with Diamond Light Source, Lawrence Berkeley National Laboratory, PAL-XFEL and SLAC National Accelerator Laboratory.
Compiled by The ScientistSomething wrong?How this is made
Why it matters
- capability Mechanisms for enzymes like IPNS have been worked out from static structures. They can now be checked against direct images of the steps in between.
- constraint Antibiotic developers gain only indirectly. The study explains how the ring is built, while resistance, as the release defines it, is microbes evolving to survive the finished drug.
- precedent IPNS's relatives, a large family of iron-dependent oxygenases that also act in human biology, are natural next candidates for the same oxygen-triggered tape method.
Oxygen starts the reaction. The team grew the enzyme as microcrystals without oxygen, put thousands of droplets of them on a moving tape 2 mm wide, and ran the tape into an oxygen-filled chamber [5]. Oxygen diffused into the crystals quickly, so the reaction began across the whole sample at the same moment [5].
Tape speed set the clock. The speed of the tape fixed how long each crystal reacted before it reached the point where an ultrafast X-ray free-electron laser pulse took an atomic-resolution snapshot [5]. The team assembled thousands of snapshots, each taken at a known delay, into a frame-by-frame sequence. It shows species that exist for fractions of a second, at physiological temperature and pressure [6].
The field had mostly relied on static crystal structures. This experiment instead followed the reaction as it ran [13]. Static crystallography has a long history with this molecule: the Oxford chemist Dorothy Hodgkin used it to solve penicillin's structure in 1945 [12]. For decades, though, the short-lived intermediates between the linear peptide and the finished ring were too hard to observe directly [8]. A time series lets the steps in between be seen instead of inferred from the two ends. The results appear in Nature Catalysis [1].
I would hold the water result most loosely. Time-resolved snapshots can show where water molecules sit at each stage of the reaction [4], but that tells you where the water is during the chemistry. Before calling it a guide, I'd want to see the reaction slow or change course when that water is displaced.
The release links the work to rising antimicrobial resistance and to the small number of new antibiotics in development. It calls understanding how nature builds these molecules an important step toward replenishing the pipeline [10]. The beta-lactam ring is a strained structure that interferes with bacterial cell wall synthesis until the wall fails [9]. The release also connects the findings to enzyme engineering as well as drug development [14]. Engineering is the shorter route. Anyone redesigning IPNS to make altered ring systems would start from a step-by-step account of what the enzyme does. The thing this doesn't tell you is how close such a redesign is. The release does not describe a candidate compound or a programme built on the result.
What to watch
- Whether the oxygen-on-tape XFEL method is applied to other iron-dependent oxygenases in the IPNS family.
- Mutation or computational studies testing whether the water molecules seen in the IPNS snapshots are required for the reaction.
- Any enzyme-engineering effort that uses the captured IPNS intermediates to produce altered beta-lactam scaffolds.
Clarity's read
What the record supports and how the coverage leans. The claims behind it follow.
Reality
- Evidence55
- Adoption
- Insufficient
- Hype gap+25
- Incentives45
- Confidence60
Claim ledger
Ranked by verification strength, evidence, and original report placement.
- [1]
Researchers from the University of Oxford and international collaborators revealed previously unseen rapid chemical stages in the formation of beta-lactam antibiotics like penicillin; the findings were published in Nature Catalysis.
- [2]
Oxford researchers, with partners from Diamond Light Source, Lawrence Berkeley National Laboratory, PAL-XFEL and SLAC National Accelerator Laboratory, used X-ray free-electron lasers to observe the enzyme isopenicillin N synthase (IPNS) as it converts its linear peptide substrate into the ring system of penicillin.
- [3]
The team captured a thioaldehyde intermediate formed just before the beta-lactam ring is created and a monocyclic beta-lactam intermediate, the first ring-shaped structure on the way to forming the complete penicillin scaffold.
- [4]
Water molecules inside the enzyme play a key role in guiding the reaction, and subtle movements throughout the enzyme help guide the chemical steps, according to the release.
- [5]
Thousands of droplets containing anaerobic enzyme microcrystals were deposited on a moving tape 2 mm wide; as the tape entered an oxygen-filled chamber, oxygen rapidly diffused into the crystals and initiated the reaction simultaneously; tape speed determined how long each crystal reacted before reaching the X-ray interaction point, where an ultrafast XFEL pulse recorded an atomic-resolution snapshot.
- [6]
Combining thousands of snapshots produced a frame-by-frame molecular movie, allowing intermediates that exist for tiny fractions of a second to be observed at atomic resolution under physiological temperature and pressure.
- [7]
According to the release, the study shows how IPNS achieves an exceptionally complex transformation in a single step, resolving a mechanistic question unanswered for more than four decades.
ReportedSupportedSource: University of Oxford release via phys.org2 sources— create a free account to open themView cited source - [8]
Scientists have studied how nature constructs the beta-lactam ring for decades, but the key fleeting reaction intermediates had been too difficult to observe directly.
- [9]
The beta-lactam ring is a highly strained ring system that interferes with bacterial cell wall synthesis, causing the cell wall to fail and the bacteria to die.
- [10]
Rising antimicrobial resistance, in which microorganisms evolve to survive the medicines designed to kill them, is undermining existing antibiotics; with too few new antibiotics in development, the release says understanding how nature builds these molecules is an important step toward replenishing the antibiotic pipeline.
ReportedSupportedSource: University of Oxford release via phys.org2 sources— create a free account to open themView cited source - [11]
IPNS belongs to a large family of iron-dependent oxygenase enzymes involved in human biology.
- [12]
Oxford chemist Dorothy Hodgkin first solved the structure of penicillin in 1945 using X-ray crystallography.
- [13]
Rather than relying on static X-ray crystallographic structures of the enzyme, the researchers followed the reaction in real time using ultrafast XFEL experiments.
- [14]
The release presents the findings as insights for enzyme engineering and antibiotic development.
