NASA credits a light spacecraft and a precise launch for Roman's 22-year fuel margin

NASA says the Roman Space Telescope now has propellant for at least 22 years of science against a planned decade, a margin built from a spacecraft that launched light and course-correction burns that came in under their allocations.

The Scientist · Science desk

Illustration accompanying NASA credits a light spacecraft and a precise launch for Roman's 22-year fuel margin

What happened

  • NASA says the Nancy Grace Roman Space Telescope has fuel for at least 22 years of potential science operations, against an original plan of five years of observations plus a five-year extension.
  • The first midcourse correction, a three-minute burn on Aug. 31 completed with better than 99% accuracy, consumed 18 kg of the 200 kg allocated to it.
  • The final maneuver into a halo orbit at L2 comes in early December, after which the spacecraft needs only periodic stationkeeping burns about every 28 days.

Compiled by The ScientistSomething wrong?How this is made

Why it matters

  • decision Twelve years of telescope time now need an owner, and the proposal queue that already holds about 50 General Observer candidates is the constituency waiting on that allocation.
  • constraint Since NASA counts propellant as the only consumable, the practical ceiling on a 22-year mission moves to hardware endurance. That is a different measure from fuel.
  • capability The coronagraph could gather results across years it was never scheduled to have. Those results feed the design case for the planet-finding mission it is demonstrating for.

Four of the extra 12 years come from the tanks. Roman weighed 8,056 kg at launch against the 9,800 kg gross/wet mass of its matured design [7], 1,744 kg under it [1], so the propellant tanks were filled to capacity rather than to the level the 10-year requirement needed [9]. The phys.org account puts that fuller load at four more years of observing [10]. Take those out of the 12 and eight years are left to the accuracy of the launch and the burns that followed [3].

"A spacecraft's mass changes throughout the design and build process, so we base the propellant budget on a set maximum value so we won't come up short," said Alison Rao, the Roman propulsion lead at NASA Goddard [8]. The budget was written against a worst case the hardware came in under.

How far the plan moved is visible in an earlier document. A 2015 design reference projected a gross/wet mass of 4,166 kg carrying only 107 kg of propellant, a low figure that reflected maintenance burns not yet well defined at the time [6]. In flight, the allocation for the first midcourse correction alone was 200 kg [11], 93 kg more than the entire 2015 propellant projection [4].

That burn ran three minutes on Aug. 31 and was completed with better than 99% accuracy, consuming 18 kg [11]. That is 9% of the allocation, and 182 kg went unspent [2].

Two maneuvers are still ahead. NASA expects the second midcourse correction to need less fuel than planned because the first was so accurate [12], and it projects the same for the insertion into a halo orbit at L2 in early December [13]. Roman is still in transit to L2 [21]. "As a result of exquisite planning by our orbital dynamics team, brilliant execution by the operations team, and a precise launch from SpaceX, Roman has fuel for at least 22 years of potential science operations," said Jamie Dunn, center director at NASA's Goddard Space Flight Center [3].

After insertion the recurring demand is a stationkeeping burn about every 28 days [14]. That is roughly 13 a year, or near 290 across a 22-year mission [5].

The first five years are largely committed, with the bulk going to the Core Community Surveys, including the High-Latitude Time-Domain Survey [16]. The planned second five belong mostly to the General Observer program, which opens the telescope to the wider astronomical community [17], and about 50 candidate GO programs are already prepared [18]. NASA has not said how the extra 12 years will be used; the phys.org report expects GO to absorb much of it, with some possibly going to the core surveys [19].

The 22-year figure describes propellant. NASA's framing is that fuel is Roman's only consumable resource and the limiting factor on mission length [4], and the announcement covers that and stops there; how long the detectors and mechanisms will keep working is a separate question. Any observing that runs past the original decade also runs the coronagraph longer, an instrument flying as a technology demonstrator for an eventual planet-finding mission [20].

What to watch

  • A NASA statement dividing the additional 12 years between the Core Community Surveys and the General Observer program, and any new proposal call that follows.
  • Coronagraph commissioning results: they decide whether the technology demonstrator earns time in the later years.
  • An updated propellant accounting after the December halo-orbit insertion. The new numbers would firm up or trim the 22-year projection.
