Mipmaps are three levers, not one checkbox: stability, residency, and meaning

A writeup published on dev.to makes a narrow but useful argument: the standard introduction to mipmaps as "smaller copies of a texture" is correct and explains almost nothing, since it does not account for why a no-mipmap screenshot looks sharp while motion shimmers, why foliage disappears, why normal-mapped highlights flash, or why an atlas bleeds only in lower levels ^[1]. The reason that matters for anyone shipping a build is that a mip chain is doing three jobs at once, according to the author: temporal image stability, allocation of bandwidth and resident memory, and a hierarchy whose levels can preserve different kinds of meaning ^[2]. Those three have different symptoms and different fixes, and one Generate Mip Maps toggle hides all of them.

Start with stability. On a 4096 x 4096 texture on a floor at a shallow angle, one screen pixel may cover hundreds of texels, so sampling mip 0 picks a tiny subset of that footprint, and a small camera move picks a different subset, which is what produces crawling detail, moire, and flicker ^[3]. Selection is driven by screen-space UV derivatives, simplified in the source as rho = max(length(ddx(texelPosition)), length(ddy(texelPosition))) and lod = log2(rho) ^[4]. Distance is not the rule; projected size, UV scale, surface angle, texture resolution, projection, bias, and anisotropy all move the result ^[5]. That is why the source insists on testing fine grids, gravel, leaves, thin text, and repeating patterns with a slow, repeatable pan, and on temporarily disabling TAA to isolate texture aliasing ^[6]. Negative mip bias gets judged the same way, in motion, because it selects higher-resolution levels and raises aliasing, bandwidth, cache pressure, and streaming demand ^[7]. Also note that trilinear filtering does not replace anisotropic filtering: a road may need anisotropic sampling even when mip transitions are already smooth ^[8].

The residency lever has the arithmetic that operators usually get backwards. Each level holds a quarter of the texels of the previous one, so 1 + 1/4 + 1/16 + ... converges to 4/3 and a full chain costs roughly 33% more texels than mip 0 alone ^[9]. Read in reverse: mip 0 is about three quarters of the chain, dropping the maximum resolution by one level leaves about a quarter of the texel count rather than half, and two levels leave about one sixteenth ^[10]. For a 4096 square texture that chain runs from mip 0 down to a 1 x 1 mip 12, thirteen levels in total ^[11][12]. Compression blocks, minimum mip storage, alignment, and platform details change the exact bytes ^[13]. Separately, the sampler may ask for mip 0 while streaming has only mip 2 and coarser levels resident, which is the blurry-after-a-cut effect that resolves a moment later ^[14].

The third lever is where content breaks. Because mip generation is filtering, the wrong color space changes the meaning of lower levels: base color is normally color, while roughness, metallic, AO, height, vectors, coefficients, LUT values, and masks are normally linear data, with HDR and emissive intensity maps as common exceptions ^[15]. Unity's Box filter is smoother; Kaiser keeps more sharpness and potentially more shimmer ^[16]. And a shader doing clip(alpha - 0.5) on a leaf that is alpha 1 against alpha 0 will lose geometry once downsampling produces boundary values such as 0.4: the average is not wrong, the surviving coverage changed between levels ^[17]. Unity exposes Preserve Coverage to adjust lower levels for that case ^[18].

Two things to watch. First, terminology: the piece is written against Unity 6.5 (6000.5) names, and inspector labels differ in 2022/2023 LTS, other Unity 6 versions, and between URP and HDRP package versions ^[19]. Second, the interaction list the author flags before enabling negative bias globally, anisotropic filtering, UV density, source resolution, render scale, and the active upscaler ^[7], plus discontinuities between render scales as a symptom to look for ^[6].
