The 680 MB database that was really a 17 GB disk: self-hosted support platforms fail at month six

An operator running self-hosted Chatwoot as the WhatsApp inbox for about a dozen small Israeli businesses got a disk alert at 86 percent and went looking at the database, which he says was the wrong place [s1 c1]^[2]. Postgres was 680 MB; the `chatwoot_storage_data` volume was 17 GB ^[3]. That is roughly twenty-five times the database, sitting in a place the default instinct never checks ^[1].

The reason is structural, not a bug. Attachments live in ActiveStorage on a Docker volume, so every image, voice note and PDF a customer sends is a file on disk and none of it appears in a database size query ^[4]. If your monitoring watches the DB, it reports healthy right up to the moment the container cannot write ^[5].

The accounting failure compounds the capacity failure. According to the author, the growth curve is a function of how many accounts you host, not how busy any one of them is ^[6]. His volume grew at roughly 0.05 GB a month until he onboarded seven new businesses over two months, after which it hit 16 GB a month ^[7]. That is a factor of about 320 in growth rate, triggered by sales, not by load ^[2]. Anyone forecasting storage from conversation volume will be wrong by two orders of magnitude on the month they close a deal.

Then there is what is actually on the volume. When he measured, almost half the outbound media was byte-identical duplicates ^[9]. One 14.5 MB video was stored 48 separate times; one image 325 times ^[10]. Chatwoot creates a new blob and a new file on every send even when the bytes match, which he calls correct behaviour for a chat app where every message owns its attachment, and expensive the moment anything fans one file out to many conversations ^[11]. In his case the fan-out was not campaigns but his own drip engine, re-reading and re-uploading the same file per conversation ^[12]. Forty-eight copies of a 14.5 MB video is 696 MB on disk to hold 14.5 MB of information ^[3].

He deduplicated after reading the Rails source, on the basis that `ActiveStorage::Blob#purge` is guarded by a foreign key on `active_storage_attachments.blob_id`, so removing one message's blob does not delete a file other messages still reference ^[13]. One pass matching on `checksum` and `byte_size` within the same account reclaimed 3.20 GB across 7,160 blobs and moved the disk from 86 percent to 71 percent ^[14]. That is about 19 percent of the volume recovered without deleting a single customer-visible message ^[4]. He recommends an index on `active_storage_blobs (checksum, byte_size)` and a size floor first, so you are not doing checksum lookups on 4 KB thumbnails ^[15].

The same measurement error shows up on the send path. `POST /api/v1/conversations/{id}/messages` returns 200 as soon as it inserts a row with `status = 0` and no `source_id`; actual delivery happens later in a Sidekiq job, and the WhatsApp message ID is written only when Meta acknowledges ^[16]. Four resend runs pushed 5,108 messages through that endpoint, the `high` queue reached 3,786 jobs with eleven minutes of latency, and inbound messages from paying customers queued behind them ^[17]. Nothing errored ^[18].

What to watch: whether your dashboard has a series for the storage volume at all, and whether your capacity plan is keyed to tenant count rather than message count ^[3][6]. His backpressure fix counts his own undelivered rows every 40 sends and pauses above 250 until the backlog drops under 80, which measures pressure he created rather than a global number he does not control ^[19]. And before any inbox deletion, note that his deleted inbox took 894 conversations and 6,160 messages with it, while contacts survived because they live at the account level ^[20].
