AIST gauges curved mirrors' absolute shape to 2 nanometres without touching them
AIST researchers built a no-contact profiler that measures the absolute shape of curved mirrors to within 2 nanometres from reflected-light angles. Makers of EUV and synchrotron mirrors have found that measurement hard to take at a few nanometres without risking the surface.
The Scientist · Science desk
What happened
- Interferometry, the usual non-contact method, compares a mirror against a reference surface or wavefront, so it struggles to deliver the absolute profile.
- An angle-measurement device called SelfA, which automatically corrects errors in its own angle scale, reads the direction of the reflected light.
- EUV and X-ray light cannot be focused by lenses, so the systems that use it rely on curved mirrors several hundred millimetres across.
Compiled by The ScientistSomething wrong?How this is made
Why it matters
- capability Polishers could check a finished mirror's departure from its design, radius of curvature included, without first making a reference optic to compare it against.
- decision Makers of multilayer-coated optics could move absolute-shape checks to after coating, the stage at which a contact probe is ruled out.
- constraint Across a 300 mm mirror, 2 nm is about 7 parts per billion of its width, so the figure cannot be assumed to hold on production-sized parts until tests at that scale are reported.
The design starts from a limit of the older tool. An interferometer measures a surface against a reference surface or wavefront, so what it reports is a comparison, and getting the absolute profile out of that is hard [5]. A slope measurement needs no reference. The AIST profiler reads the local angle of the mirror at each position from the direction of the reflected light, across a wide range of angles. The absolute profile then follows from how those angles vary along the surface [3]. The paper calls the instrument a scanning deflectometric profiler [12].
Every point of the profile is computed from angles, so the angle measurement sets the accuracy. To read the reflected light's direction precisely, the team built in SelfA, an angle-measurement device that automatically corrects errors in its own angle scale [4]. With it, AIST reports non-contact measurement of the absolute profile of curved mirrors to 2 nanometres [2].
The users are the instruments that cannot use lenses. Short-wavelength light such as EUV and X-rays is hard to transmit and cannot be focused by lenses, so these systems steer it with curved mirrors several hundred millimetres across [8]. The same kind of precision mirror is used in EUV lithography, synchrotron facilities, astronomical telescopes and gravitational-wave detectors [9]. Their makers measure how far a finished surface departs from the design, radius of curvature included, and then correct it [6]. Some of these optics carry multilayer coatings, and a measurement that touches the surface could damage them [7].
The thing the 2 nm figure doesn't tell you is the size of mirror it was measured on. Take 300 mm, the low end of "several hundred millimetres". Holding 2 nm across that width is about 7 parts per billion [1]. The release does not give the size or curvature of the test mirrors, the scan time, or the independent measurement the 2 nm result was checked against. A production line would need all of those before it replaced an interferometer in its correction loop.
I think the method meets a need the field has stated plainly. According to the AIST account, measuring curved mirrors to a few nanometres without damaging them has been difficult, and demand for such a tool has been strong [10]. The evidence so far supports a working instrument. AIST's claim for manufacturing is a forecast: the account says the technology "is expected to support the manufacturing, development and evaluation of advanced optical components for high-performance optical systems" [11].
What to watch
- Whether the Precision Engineering paper reports the test mirrors' size and curvature, and what independent measurement the 2 nm result was verified against.
- Whether an EUV lithography or synchrotron mirror maker adopts the profiler in a polishing-correction loop, and how its scan time compares with interferometry.
