ZSvirt's VMware-exit PoC guide tells you to break the VM build on purpose
The checklist is sound on day-two operations and on the order it runs tests in, but the one-server build it recommends cannot execute the host-to-host migration step, and access control never gets exercised at all.
The Engineer · Build desk

What happened
- A PoC guide from the ZSvirt community argues that creating and booting a single VM verifies only the most basic compute path when you are evaluating a replacement for VMware.
- It starts with an inventory: counts of vCenters, clusters, hosts and VMs, CPU generations and retention plans, disk and snapshot patterns, VLANs and address allocation, OS versions, and downtime tolerance.
- The minimal build runs in sequence after the ISO install: datacenter, cluster, hosts, data storage, image storage, a distributed switch with port groups, then the first VM.
- The ongoing exercises include expanding disks, adding and removing data disks, snapshot restore, spec changes, network changes, migrating a VM to another host, and simulating an operation that fails halfway.
Compiled by The EngineerSomething wrong?How this is made
Why it matters
- constraint The one-server build caps what the checklist can prove: nothing in the migration or cluster half executes until a second host is racked, so the real hardware floor is two.
- decision Finishing the inventory before installing anything is what keeps the PoC scoped to your environment instead of to a lab nobody runs in production.
- contradiction Because access control and HA sit in the scope statement but not in the exercises, a PoC executed exactly as written can pass without a single permissions or failover test.
- cost With no throughput or duration figures supplied, every cutover-window estimate has to come from your own measurement, and that measurement is the expensive part of the evaluation.
The most instructive step in the list is the one that asks you to break something. According to the guide, creating a VM decomposes underneath into scheduling a compute node, preparing an image, creating disks, configuring networking and generating the VM config, and a failure at any of those steps can leave behind resources that were created and are no longer needed [13]. The stated answer is async tasks, stateless services and a workflow engine that splits long-running operations into executable, rollback-able steps [12][14]. That makes the induced-failure exercise [15] a reconciliation test rather than an error-message test: after a failed create, the platform's inventory either matches what is actually on the disks and the switch, or it does not. Orphaned volumes are easy to ignore in a lab and expensive to find in production.
Then the arithmetic. The minimal build puts the management node and the compute node on a single server [7]. The exercise list asks you to migrate a VM to another host [11]. One host cannot receive a migration from itself, so the floor for running the whole checklist is two hosts, not the one the deployment section describes [17]. The wording matters a second time: the list says migrate a VM to another host, and does not say whether the VM stays running while it moves [20]. That distinction decides whether anything without a maintenance window can move at all, and the same guide asks you to sort workloads by tolerance for downtime versus a short cutover window in the inventory step [5].
Two items in the scope statement never reach the exercises. Access control and high availability both appear in the list of what a larger infrastructure team has to evaluate [6], and neither gets a step in the day-two list or in the post-boot checks [18]. The text available breaks off mid-sentence while introducing the controlled-failure example [19], so a later section may close that gap. Up to that point, a PoC run to the letter proves the storage, network, image, console and task-record paths [9] and says nothing about who is permitted to invoke them.
No figures accompany any of it [21]. The guide points back to an earlier post on the architecture of what it calls a production-proven engine [16], which is a claim about someone else's environment until you produce numbers from yours. For the checklist to transfer, the inventory has to be finished before you install anything: CPU generations and the hardware retention plan, VLANs and address allocation and security policy, and how backup, monitoring, audit and automation attach [5]. Those set the scope, and the platform's feature list does not. The sequencing rule is the part I would copy verbatim: confirm the compute, storage, network, image and VM paths before touching cluster and migration tests, so a later failure can be attributed to platform configuration, infrastructure conditions or the migration process itself [10]. What you get, as published, is a competent day-two operations drill on one host with no permissions step, which leaves the two questions that usually block a VMware exit for you to add.
What to watch
- Whether ZSvirt documents if host-to-host migration keeps the VM running, and under which storage layouts.
- Whether the sections after the truncated controlled-failure example add RBAC and HA failover steps to the exercise list.
- Any migration throughput or cutover-window numbers from a team that ran this checklist on its own hardware.
