Topograph turns fabric discovery into Kubernetes labels and Slurm's topology.conf

Topograph discovers and publishes topology; it does not schedule anything. It splits into providers and engines: a provider discovers topology and normalizes it into one canonical model, and an engine translates that model into Slurm configuration, Kubernetes labels, Slinky ConfigMaps, Node Feature Discovery resources, or an instance-oriented topology JSON ^[2]. The toolkit is open source ^[3]. The integration surface is therefore a config artifact the scheduler already reads.

Slurm and Kubernetes both already support topology-aware allocation, and both can only act on the topology they observe ^[15]. Five components keep Topograph's view current, and the first one I would size is the API Server, which validates requests, aggregates duplicates and dispatches discovery ^[18].

The bandwidth gap here is wide. NVIDIA puts fifth-generation NVLink at 1.8 TB/s of bidirectional bandwidth per GPU on Blackwell parts such as GB200 and GB300, and sixth-generation at 3.6 TB/s per GPU on Vera Rubin, over a dedicated NVLink Switch fabric ^[12]. It puts a modern Quantum InfiniBand port at up to 800 Gb/s ^[11]. In the same units, 1.8 TB/s is 14,400 Gb/s, which is 18 of those ports, and 3.6 TB/s is 36 of them ^[19]. For that ratio to describe a job of yours, the collective has to be bandwidth-bound and all-to-all, which is the traffic pattern NVLink's non-blocking design is built for ^[13].

Two lines in the support matrix cost real work to satisfy. The Slurm engine will run inside Kubernetes, but it requires a writable volume for its configured topology.conf output path ^[9], so the scheduler's topology file becomes a mounted artifact that someone has to own. The Crusoe provider reads fabric and accelerator-domain labels from Crusoe Managed Kubernetes nodes, which means Topograph itself runs in Kubernetes there ^[8]. The matrix is dated to upstream main as of September 16, 2026, and NVIDIA says requirements can vary by Topograph version, environment and provider configuration ^[7].

NVIDIA argues the case on power, describing AI factories as power-limited systems in which GPU workload placement is a key optimization ^[22]. The post itself is a deployment walkthrough covering Kubernetes, Slurm and Slinky ^[21]. Inside the DSX OS orchestration layer, the placement decisions stay with Dynamic Resource Allocation and the KAI Scheduler, which consume the published topology for gang scheduling ^[17].
