A .class file is a byte-layout problem: cafebabe, big endian, and 12 pool entries

A dev.to post, part two of a series whose first instalment built a Brainfuck interpreter with a tokenizer, parser and intermediate representation, opens a compiled `Hello.class` with `xxd` and then rebuilds the same structure from scratch in Node.js ^[1][2]. The framing is worth borrowing, because the file the JVM expects is raw bytes in a structure fixed by the JVM specification ^[3], which makes emission an accounting job rather than a compiler-theory job.

Start with the header. Every `.class` begins with the four bytes `CA FE BA BE`, and the JVM refuses the file outright if they are absent ^[4]. The next four are the version: `0000` minor, `0034` major, which is 52, which is Java 8 ^[5]. Two more bytes give the constant pool count ^[6]. Four plus two plus two plus two is ten, which is exactly why the first pool entry in the dump sits at offset `0x0a` ^[7].

Then byte order. The JVM stores multi-byte numbers big endian, most significant byte first, while the x86 or ARM chip running your generator is probably little endian ^[8]. In Node the conversion for a 16-bit value is a single return statement: `(num >> 8) & 0xFF` for the high byte, `num & 0xFF` for the low, with more shifts of the same shape for four-byte fields ^[9][10]. Get it backwards and nothing traps at the site of the mistake, because the swapped bytes are still a legal number: `0x7530`, 30000, reads as `0x3075`, 12405 ^[11]. The post's debugging heuristic is the practical takeaway. If a generated class produces strange constant pool errors, check that you are writing big endian ^[12].

The pool itself is where the bookkeeping gets fiddly. For this `Hello.class` the count field is `0x000d`, 13, but indices start at 1 and the count is always n plus 1, so there are 12 entries ^[13]. The source program is a class with one method whose body is `return` ^[14], so twelve entries is the floor, not the interesting case ^[15]. Each entry opens with a tag byte, and the entries point at each other: entry 1 is `0a 00 02 00 03`, a CONSTANT_Methodref with class index 2 and name-and-type index 3, resolving to the superclass constructor `Object.<init>()V` ^[16]; entry 2 is `07 00 04`, a CONSTANT_Class naming index 4 ^[17]; entry 4 is tag `01`, a CONSTANT_Utf8 of length `0x0010` holding the 16 bytes `java/lang/Object` ^[18]. Bytecode never stores a string inline. Everything is reached through the pool by index ^[19].

Types get their own encoding. `main` is not recorded as `void main(String[] args)` but as `([Ljava/lang/String;)V`, in the form (parameters)return, sitting in the pool as a Utf8 and referenced by index ^[20][21].

What to watch is the part the post defers. From major version 50, Java 6, the StackMapTable attribute is mandatory ^[22], so a generator targeting version 52 owes the verifier frames that no source-level construct asked for. That is the point where hand-rolled emission stops being transcription of a layout and starts requiring you to model the operand stack yourself. The post says that is part three ^[23]; the byte-layout half, on this evidence, is the cheap half.
