systemd's mstack mounts a single-layer stack writable by default

The overlayfs model behind mstack has two kinds of layer: read-only lowers and one writable top ^[1]. In the directory format, the lowers are symlinks named layer@0, layer@1 and so on, and the writable top is an rw/ subdirectory ^[5]. In a correctly built stack, writes go to rw/ and the lowers stay untouched ^[1][5]. For a stack with a single layer, the dev.to post reports that mstack mounts it writable by default ^[4]. The overwrite was permanent. So the write did not stop in a scratch upper directory. It reached the file the layer pointed at ^[1].

For automation, the exit status is the bigger problem. The mount returned 0, with no error and no warning ^[3]. A provisioning script that checks $? sees success. The only check that catches the write-through is a test write followed by a look at the source directory.

The service paths matter because nspawn and RootMStack= read the same directory ^[6]. The author ran every test in Docker against 261.3, because the sandbox had no systemd running as PID 1 ^[7]. With no systemd as PID 1, no service using RootMStack= could have run, and every command shown in the post is systemd-mstack ^[2]. The published portion of the post does not show which option or layout keeps a one-layer stack read-only. Until that is documented, I think the safe assumption for a unit file is that a single-layer stack writes through.

Docker is also where the failure path goes wrong. The hand-written equivalent, mount -t overlay, fails there with "overlay: filesystem on upper not supported as upperdir" ^[9]. The kernel will not build an overlay on directories that already sit on overlayfs, and that limit predates 261 ^[9]. The author wrote that mstack explains the failure worse, because its message names an internal function, (layerfd), instead of the actual constraint ^[13]. Most people's first instinct is to test inside a plain Docker container, the author wrote, so most evaluators will get the confusing version first ^[14]. Putting the layers on tmpfs or on a bind-mounted host directory avoids the problem. An ext-family host directory mounted cleanly with exit 0 ^[10].

The rest of the design is careful work. The docs order layers by version sort so that layer@10 does not land before layer@2. The author's test with layer@1 to layer@3 and layer@10 to layer@12 came back in numeric order ^[11]. Over five mounts each of a two-layer stack on tmpfs, mstack ran roughly a millisecond slower than the hand-written command ^[12]. The author attributed the gap to resolving symlinks and building the option string ^[12]. The number applies to stacks shaped like the test: two layers on tmpfs. I'd expect the cost to rise with each extra symlink to resolve, and the post measured two layers.
