Ten-year LTE-M battery numbers rest on PSM timers the network overwrites at attach

The byte is where the first mistake happens. T3412 extended and T3324 are each a single octet encoded per 3GPP TS 24.008, with the three most significant bits selecting a unit and the five least significant bits carrying a multiplier ^[5]. In the T3412 table, 01000011 is 10 hours times 3, so 30 hours ^[6]. In the T3324 table, 00001000 is 2 seconds times 8, so 16 seconds ^[7]. The unit codes do not line up between the two tables: 000 is 10 minutes in T3412 and 2 seconds in T3324, so decoding one with the other's table moves the answer by a factor of 300 ^[8]. Mixing the tables is the one bug here that a code review can actually catch.

A request of AT+CPSMS=1,,,"00100100","00001010" asks for 4 hours of T3412 and 20 seconds of T3324 ^[9]. That nets 3 hours, 59 minutes and 40 seconds of sleep per cycle, because active time comes off the TAU period ^[4]. What comes back can be shorter, or it can be the non-extended T3412 format with its lower ceiling, or PSM can be deactivated outright, and none of those paths raises an error ^[13].

Take the DevZone case at its granted value. A 4-hour TAU forces 2,190 TAU cycles a year: 365 x 24 / 4 ^[21]. Fifty-four minutes forces 9,733: 365 x 1440 / 54 ^[22]. That is 7,543 extra wakeups per device per year, roughly 4.4 times the design figure ^[23]. I am not converting that into months of battery, because energy per TAU depends on the modem, the RF conditions and the supply. The multiplier on its own is enough to void a ten-year figure produced from requested timers ^[20].

eDRX repeats the pattern with a different command. AT+CEDRXS=2,4,"1001" requests the 163.84-second Cat-M1 cycle on LTE-M ^[17], and the available cycle lengths are fixed by the standard, so there is no partial credit ^[24]. AT+CEDRXRDP returns the access technology, the requested value, the network-provided value and the Paging Time Window; when the middle two differ, your cycle was replaced with the network's ^[18]. Qoitech, measuring with an Otii Arc Pro, found that a device requesting one cycle and receiving another draws a profile matching neither the requested configuration nor the datasheet's nominal figure, and concluded that "these differences are impossible to detect in firmware logs or modem responses" ^[19]. Lose eDRX and the device is back to waking every 1.28 or 2.56 seconds to check for pages ^[16].

So the condition for a profiler's ten-year number to transfer to your fleet is narrow and testable. The granted T3412 read out of AT+CEREG has to equal the one you requested ^[11], and the network-provided eDRX value out of AT+CEDRXRDP has to equal what you asked for ^[18], on every network the fleet attaches to. Both comparisons run at attach and cost one AT command each. That is the whole audit.
