JetBrains' Service Map draws the architecture from each span the moment it arrives
The OpenTelemetry plugin classifies spans off their attributes and folds each one into an architecture model on arrival. A trace never signals that it is complete, so the algorithm never waits for one.
The Engineer · Build desk
What happened
- JetBrains has shipped a Service Map in its OpenTelemetry plugin that auto-generates an architecture map from runtime data, built by the Rider Execution team with Software Engineering Research.
- Starting the IDE with the plugin enabled starts a lightweight local OpenTelemetry backend, which processes the telemetry the running application sends to it.
- The map is built from traces rather than logs or metrics, on the grounds that traces show a request's journey through the system and are made up of spans.
- Spans arrive independently in no guaranteed order, and JetBrains says a parent span can finish and arrive after its own child has already been processed.
Compiled by The EngineerSomething wrong?How this is made
Why it matters
- cost The plugin does nothing for a team that has not instrumented: the run sequence assumes an application already emitting spans, so the bill is OpenTelemetry SDK work in each service, paid before any diagram appears.
- capability One tool can map a polyglot estate with no per-language support, provided every library in the path emits spans the way the OpenTelemetry conventions specify.
- constraint What you get is a picture of the instrumented processes that exported to the local backend during that run, so the map doubles as a report on your instrumentation coverage and your test traffic.
A trace never explicitly says it is done, and JetBrains says the plugin can never be 100% sure a late-arriving span is not about to show up [8]. So it does not wait for one: the reconstruction is written as a stream algorithm that processes every span the moment it lands, instead of holding out for a complete trace [10]. Clicking the Service Map tab fetches whatever structural model the backend holds at that instant and renders it [6].
Classification is attribute inspection, and it has to be. OpenTelemetry does not provide a strictly typed version for each span type; each span carries a key-value map of attributes, and the plugin deduces what interaction it is looking at by reading them [9]. Attributes such as `http.request.method` and `http.response.status_code` say HTTP call, while other attribute sets point at a database query or a message queue interaction [11]. Classification depends on the span carrying the attributes the classifier reads [2]. JetBrains does not quantify how complete the resulting map is.
The stack-independence claim is conditional. The post says the plugin can visualize a system completely independently of your technology stack, "as long as your app and libraries emit spans the way OTel expects" [12]. The condition matters, because the classifier keys on specific attribute names [11].
The opening case in the post is the diagram that is six months out of date, where "Service A hasn't talked to Service B since the spring, and there's a new message queue nobody bothered to document" [13]. Trace data handles the second half well: an undocumented queue that carries traffic emits spans, and spans put it on the map [3]. The first half comes back in a new shape. A missing edge means either the call no longer happens or nothing triggered it while the backend was collecting, and the rendered model does not separate those two [3].
JetBrains calls a map built this way "the source of runtime truth", on the grounds that it is not guessing from source code or outdated specs [16]. Measured against static analysis, which the post says "often fails to capture how services are actually wired together at runtime" [14], that comparison holds for the code paths that ran.
What to watch
- Whether the classifier grows past HTTP, database and message queue interactions, and which attribute keys it reads for each new one.
- Whether services the IDE did not launch can be pointed at the local backend; that would widen the map beyond one process tree.
- Whether the internal model persists across runs or resets each time, since that decides what a missing edge means.
